Biomass hot blast stove ZDFR-B
Biomass hot blast stove ZDFR-B
Product Category:Hot blast stove series
Biomass fuel hot blast stove is an innovative product specially developed by our company based on the production situation of users to meet the market demand of energy conservation and emission reduction. Mainly burning crop straw, rice husk, bark, wood chips and other biomass fuels instead of coal. Hot blast stove has the characteristics of easy ignition, fast heating, full combustion, high burnout rate and stable heating. Automatic control system, mechanical and electrical integration operation, easy operation, with self-reducing explosion-proof valve, can effectively prevent the hatake during the production of explosion-bursting and other hidden dangers.
Product Introduction

1.Product introduction

Biomass fuel hot blast stove is an innovative product specially developed by our company based on the production situation of users to meet the market demand of energy conservation and emission reduction. Mainly burning crop straw, rice husk, bark, wood chips and other biomass fuels instead of coal. Hot blast stove has the characteristics of easy ignition, fast heating, full combustion, high burnout rate and stable heating. Automatic control system, mechanical and electrical integration operation, easy operation, with self-reducing explosion-proof valve, can effectively prevent the hatake during the production of explosion-bursting and other hidden dangers.

2.Main performance and characteristics

(1)Wide fuel adaptability, combustible crop straw, rice husk, bark, sawdust and other biomass pellet fuel;
(2)High combustion efficiency, full combustion, burning degree more than 99%, Thermal efficiency more than 96%;
(3)Stable heating, uniform temperature, heating temperature below 8000 stable and adjustable;
(4)A variety of control modes, manual/automatic control and intelligent control for users to choose.

Product parameter introduction

Technical parameters/models Heating capacity
kJ/h
Coal consumption
kg/h
  Furnace body dimensions
Length x width x height mm
Furnace weight t
(reference)
ZDFR-B-2 2×4.18×10? 500 4504×3460×4800 110
ZDFR-B-4 4×4.18×10? 1000 5316×4156×5400 150
ZDFR-B-6 6×4.18×10? 1100 6016×4968×5800 200
ZDFR-B-8 8×4.18×10? 2000 6132×5780×6300 240
ZDFR-B-12 12×4.18×10? 3000 7060×6940×7100 300
ZDFR-B-16 16×4.18×10° 4000 7520×7404×7800 400
ZDFR-B-20 20×4.18×10° 5000 8100×7170×8940 450
ZDFR-B-25 25×4.18×10° 6250 8330×7400×9360 500
ZDFR-B-30 30×4.18×10? 7500 8930×7656×10020 600
ZDFR-B-35 35×4.18×10? 8750  9140×7780×10500 750



Note: The fuel in the table is biological particles, and the calorific value is 4000kcal/kg(T)(Table selected part of conventional furnace type)
